LEDSON Sarox9+ high beam light LED 120W

Specifications:

With position light, yellow-orange or xenon white (connect the color you want)

Combo beam pattern

E-marked ECE R112 (Ref. 45), R10 / R7 (white position light) - Read more about UNECE regulations here

Range: 938 m (0,25 lux), 469 m (1 lux)

EMC secured

12000 lumen (raw), 10200 lumen (actual)

Cold white light (5700K)

TIR (Total Inner Reflection)

ETM (Electronic Thermal Management)

Side reflective optical system

Pressure equalization membrane

Aluminum heatsink

Adjustable bracket in stainless steel

Lexan polycarbonate front cover

Polycarbonate Lens

36 month warranty

Technical data:

120W (4 x 20W Cree LED + 4 x 10W Cree LED)

IP68/IP69K (water and dust proof)

DT connector 4 pin supplied

Voltage 9-36 V

Main light load: 8.1A @ 12V and 4.4A @ 24V

Position light load: 0,9A

Dimensions & weight:

Width: 218 mm

Height: 218 mm (233 mm incl bracket)

Depth: 84 mm

Cable length: 42 cm

Weight: 1,8 kg

Supplied:

Ledson Sarox9+ LED light 9"

Bracket, bolts and screws for attaching the auxiliary light with either one or two attachment points

DT connector (4-pole)

Installation instructions

DT adapter

Installation instructions for cables (detailed instructions included with the product):

Red: Auxiliary light (+)

Black: Auxiliary light / Position light (- ground)

White: Position light (+) white light

Yellow: Position light (+) yellow-orange light

NOTE: The DT connector must not be cut, as this increases the risk of moisture damage and the warranty will cease to apply.
